IM C8000 A3 colour multifunction printer

  • Copy, print, scan, optional fax
  • Prints up to 80 ppm
  • 8,100-sheet max input
  • Continuous updates via RICOH Always Current Technology

Download PDF Brochure

Get in touch

Simple, secure and scalable, the RICOH IM C8000 is a productive and long-term solution to your rapidly evolving business needs. Delivering immaculate colour and black and white output at 80ppm, this device will allow you to produce professionally presented print collateral in-house. And with our intuitive 10.1-inch Smart Operation Panel running the latest applications, they really couldn’t be easier to use.

Our high-performance colour MFPs will intelligently meet your business needs

  • Stunning colour and black and white output is delivered at production pace
  • Mobile workers can interact seamlessly with the Intelligent Devices
  • Paper-based documents can be quickly digitised and uploaded to the Cloud
  • You can install new features and applications as your business requirements change

Ricoh Dynamic Workplace Intelligence

Your needs change. Ricoh intelligent devices change with you.

Take traditional office printing capabilities into new realms by connecting reliable print hardware with smart software, scalable technology and sophisticated applications, making everyday workflows easier, faster and more secure.

Find Out more

Specifications

Functions
Print, copy, scan and fax (optional)
HDD
640 GB (320 GB x 2)
Memory - Standard
4 GB
Operation Panel
10.1-inch Smart Operation Panel (G2.5)
Physical Dimensions
Mainframe: 750 x 880 x 1,225 mm
869 x 730 x 658 mm—2,200-sheet LCT RT4070
352 x 540 x 625 mm—4,400-sheet LCT RT4060
520 x 514 x 207 mm—A3 Tray Type M26
350 x 513 x 192 mm—Copy Tray Type M42
540 x 600 x 660 mm—9-bin Mailbox CS4010
218 x 173 x 55 mm—Small Paper Feeding Unit Type M37
657 x 730 x 980 mm—2,000-sheet Booklet Finisher SR4160
657 x 730 x 980 mm—3,000-sheet Finisher SR4150
806 x 730 x 980 mm—3,000-sheet Finisher SR4140
209 x 730 x 980 mm—Multi-Folding Unit FD4010
470 x 730 x 980 mm—Multi-Folding Unit FD4020
540 x 730 x 1,270 mm—Cover Interposer CI4050
500 x 600 x 600 mm—Cover Interposer CI4040
143 x 539 x 218 mm—Output Jogger Type M25
Weight—Other
250 kg or less
83 kg or less—2,200-sheet LCT RT4070
21.3 kg or less—4,400-sheet LCT RT4060
11 kg—A3 Tray Type M26
2.2 kg or less—Copy Tray Type M42
15 kg or less—9-bin Mailbox CS4010
0.19 kg—Small Paper Feeding Unit Type M37
58 kg or less—2,000-sheet Booklet Finisher SR4160
61 kg or less—2,000-sheet Booklet Finisher SR4160 with punch unit
38 kg or less—3,000-sheet Finisher SR4150
41 kg or less—3,000-sheet Finisher SR4150 with punch unit
77 kg or less—3,000-sheet Finisher SR4140
45 kg or less—Multi-Folding Unit FD4010
92 kg—Multi-Folding Unit FD4020
45 kg or less—Cover Interposer CI4050
12 kg or less—Cover Interposer CI4040
2 kg or less—Output Jogger Type M25
Standard input capacity (sheets)
3,700
Maximum input capacity (sheets)
8,100
Maximum output capacity (sheets)
3,500
Physical Dimensions

Plain paper1, recycled paper, colour paper, special paper 1–3, letterhead, pre-printed paper, pre-punched paper, bond paper, card stock, thin paper, plain paper 1–2, middle thick, thick paper 1–4 1—Not displayed as paper type

Paper thickness
52.3–65.9 g/m2—thin paper
66–80.9 g/m2—plain paper 1
81–100.9 g/m2—plain paper 2
101–127.4 g/m2—middle thick paper
127.5–150 g/m2—thick paper 1
150.1–216 g/m2—thick paper 2
216.1–256 g/m2—thick paper 3
256.1–300 g/m2—thick paper 4
Maximum paper size
SRA3++
Media weight (g/m2)
52.3–300
Interfaces - standard
10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet)
USB Host Type A—2 ports
USB Device Type B—1 port

Smart Operation Panel
IEEE 802.11 b/g/n (Wireless LAN)1
Bluetooth 4.22
SD Card Slot—SDHC memory card
USB Host Type A—USB Flash memory
USB Host Type A—1 port for USB keyboard (optional)2
USB Host Type mini B—for NFC card reader (optional)2
microSD card slot—ROM storage expansion2
NFC Tag2
Interfaces - Optional
IEEE 1284
Wireless LAN (IEEE 802.11 a/b/g/n)
Device Server Option Type M37 (additional NIC port)
Copy Connector Type M25
Network capable
Yes
Network protocols - standard
TCP/IP (IPv4, IPv6)
Copy speed
80 cpm
First copy time
4.8 seconds—black and white, 6.4 seconds—colour
Copy resolution
600 x 600 dpi
Zoom range
25%–400% in 1% steps
Enlargement ratios
400%, 200%, 141%, 122%, 115%
Reduction ratios
93%, 82%, 75%, 71%, 65%, 50%, 25%
Duplex copy
Simplex to duplex, duplex to duplex—with SPDF, book to duplex, front and back to duplex
Book copy
Booklet, magazine, layout, and booklet
ID card copy
Supported
Print speed - black and white
80 ppm—A4 LEF, 42 ppm—A3 SEF, 85 ppm—A5 LEF
Print speed - colour
80 ppm—A4 LEF, 42 ppm—A3 SEF, 85 ppm—A5 LEF
Printing process
4-drum dry electrostatic transfer system with internal transfer belt
Print Resolution
Resolution
1,200 x 4,800 dpi

Page description languages (PDLs)
Standard
PCL 5c, PCL 6, PostScript3 emulation, PDF Direct emulation

Optional
Adobe PostScript 3, Adobe PDF Direct, XPS, IPDS

Printer Drivers
Standard
PCL 5c, PCL 6, PostScript3 emulation

Optional
Adobe PostScript 3

Duplex printing
Standard
Maximum printable area
323 x 480 mm
Scan speed
A4

Colour
120 ipm—simplex LEF via SPDF
240 ipm—duplex LEF via SPDF
Scan methods
Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded)
Scan resolution
100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi, 1,200 dpi
Scan to file types

Single- and multi-page TIFF

Single-page JPEG

Single- and multi-page PDF, PDF/A

Single- and multi-page High-Compression PDF
Scan to folder

Protocols
SMB, FTP, WSD (Web Services on Devices for Scanning), DSM

Security
Client folder logon, transmission encryption of logon name and password

Resolution
100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi

Client folder addresses stored in HDD
Maximum registered folder addresses—2,000
Maintain folder addresses via operation panel, SmartDeviceMonitor for Admin, Web Image Monitor

Destination folder address input via operation panel
Supported

Search for client folders
SMB—browsing directly to the designated folder
FTP—by folder name

Homefolder over LDAP
Supported

Maximum client folders/PCs per send
50 folders

Simultaneous transmission
550 destinations maximum when combined with Scan to email

Maximum group addresses
100 destinations from a maximum of 50 folders, 500 email addresses maximum per group

Input file name
Supported

Maximum file size
Default - 2,000 MB

Scan to folder file types
TIFF, JPEG, PDF, PDF/A, High-Compression PDF
TIFF, PDF, PDF/A, High-Compression PDF

Resend
Yes—default/No
TWAIN scanning

Scan mode
Standard, Photo, OCR, Filing

Scan resolution
100–1,200 dpi

Scan speed—SPDF
Black and white: 205 ipm—single-sided 173 ipm—duplex
Colour: 115 ipm—single-sided 204 ipm—duplex

Image adjustment
Brightness, Contrast, Threshold, Gamma Adjustment, Half‑tone Pattern

Endorse
Supported

Stamp originals
Date, Page number, Text

Supported operating systems
Windows 7, Windows 8.1, Windows 10, Windows Server 2008, Windows 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Fax types
G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
Fax circuit
PSTN, PBX
Fax compatibilty
ITU-T (CCITT), G3—maximum 3 lines
Fax modem speed
2,400 bps–33.6 Kbps—G3, standard with automatic shift down
Fax compression methods
MH, MR, MMR, JBIG
Fax resolution
Standard mode
200 x 100 dpi—8 x 3.85 lines/mm

Detail mode
200 x 200 dpi—8 x 7.7 lines/mm

Super fine mode
400 x 400 dpi—8 x 15.4 lines/mm
400 x 400 dpi—16 x 15.4 lines/mm

G3 fax transmission speed
2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission
Page memory size
Standard—4 MB, With optional SAF memory—8 MB
Fax SAF memory capacity

Standard
4 MB—approximately 320 pages

With optional SAF memory
64 MB—approximately 4,800 pages
Quick dials
2,000 numbers
Data Overwrite Security System (DOSS) - Standard
Yes
Encryption
HDD encryption—HDD option required
PDF, Secure print, WEP, WPA encryption
Authentication password encryption
Encryption of data sent via Scan to email and Fax forwarding (S/MIME)
Encryption
802.1x wired authentication
IEEE 802.11i security (WEP, WPA)
IPv6
Network user authentication
Quota setting/Account limit
User authentication—Windows and LDAP via Kerberos, basic, user code
User code authentication
Wi-Fi Protected Setup (WPS) support
Windows Environments
PCL 5c, PCL 6, and PostScript 3
Windows 7
Windows 8.1
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows 10
Windows Server 2016
Windows Server 2019

Macintosh
OS X Native v10.12 or later—PostScript 3 only
UNIX
Sun Solaris—10
HP-UX—11.x, 11iv2, 11iv3
Red Hat Linux—Enterprise v4, v5, v6
SCO OpenServer—5.0.7, 6.0
IBM AIX—6.1, 7.1, 7.2
SAP
Environment—R/3, S/4
Platform—SAP R/3 (Release versions 3.0 and higher), SAP R/3 Enterprise, mySAP ERP (2004 and higher), SAP HANA
Page Description Language (PDL)—PCL
Character set—Latin-1, Latin-2, Unicode
Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS Postnet, UPC/EAN
OCR fonts—OCR A, OCR B
Supported languages
Default


Selectable by user


Selectable by administrator


Power consumption
2,400 W or less—maximum power
1,324.7 W or less—operating power, black and white
1,473.7 W or less—operating power, colour
191.45 W—Ready Mode
170 W—Low Power Mode
0.74 W—Energy Saver Mode (Sleep Mode)
60 W or less—SPDF
85 W or less—2,200-sheet LCT RT4070
50 W or less—4,400-sheet LCT RT4060
48 W or less—9-bin Mailbox CS4010
67 W—2,000-sheet Booklet Finisher SR4160
67 W—3,000-sheet Finisher SR4150
100 W—3,000-sheet Finisher SR4140
60 W or less—Multi-Folding Unit FD4010
240 W—Multi-Folding Unit FD4020
84 W or less—Cover Interposer CI4050
43 W or less—Cover Interposer CI4040
15 W or less—Output Jogger Type M25
Typical Electricity Consumption (TEC)
1.651 kWh (nominal), 2.049 kWh (guaranteed)
Warm-up time
40 seconds
Power saving mode
45 minutes shift time—Energy Saver Mode (Sleep Mode), 15 minutes shift time—Low Power Mode
Recovery time
38 seconds—Energy Save Mode (Sleep Mode), 7.9 seconds—Low Power Mode
Identification of plastic components
All plastic components are identified in accordance with ISO 11469 standard.
Other Environmental Features
Eco-friendly indicator screen, System reset timer
